The Kestrel TSCM™ Professional Sofware takes full advantage of advanced Sofware Defined Radio (SDR) concepts to deliver proven industry leading, standalone RF remote spectrum monitoring, collection and analysis functionality. Work flow oriented features tailored to professional level TSCM applications and integrated into an intuitive operator centric graphical user interface, contribute to a high standard of usability. With its extensive functionality, the Kestrel TSCM™ Professional Software is the ultimate future‐proof radio frequency sensing solution for TSCM. Our Technical Research and Standards Group (TRSG) continues to develop unique and innovative products and deployment methods. Software supports a broad range of search receivers and spectrum analyzers, and is available to technical security professionals worldwide.

Key features:
Graphical User Interface (GUI) Ergonometric user interface design promotes operator situational awareness by grouping and dynamically linking essential control elements and use of intelligent automation. RF Spectrum Display (RSD) Multiple spectrum tabbed window displays permit any number of frequency Ranges of Interest (ROI) to be searched in parallel. Waterfall Display (WFD) Waterfall Display (WFD) and trace recording capability enables the time history of signal events to be instantly reviewed. Live View Analysis (LVA) ^TMRealtime analysis of continuous and periodic signal events is fully supported without the need to interrupt the data collection process. Artificial Intelligence Our Threat Detection Algorithm (TDA) and Signal Combining Technology (SCT) accurately detects and displays wide bandwidth signals. Kestrel Super Trace (KST) During remote spectrum surveillance and monitoring over a period of days, weeks, or months, waterfall and trace data can become a storage challenge, and may require extensive post event analysis and review. Our unique data write management feature, in combination with the ability to compress the trace data is a powerful innovation that significantly improves the technical operators analysis and review capability. Waterfall compression method enhances the user‐interface rendering, bringing clarity to the waterfall display. This unique functionality permits the technical operator to easily observe periodic peak energy patterns across the Range of Interest (ROI) over time.	Demodulation and Visualization The operator can quickly demodulate and record samples of AM, FM and SSB audio. Realtime displays include RF power spectrum, AF power spectrum, audio oscilloscope, IQ and RSSI. Threat Detection Algorithm (TDA) Detecon modes include, Minimum Detecon Amplitude (MDA), Harmonic Signature Threshold (HST), and Chirp Threat Mode (CTM). Differenal Signal Analysis (DSA) TM Our graphical DSA model permits the import of floor plans, vercal riser, geographical maps and photographs of the target area for direct comparave analysis of all collected data. Spectrum Baseline Logging (SBL) ^TM The technical operator can quickly capture a detailed baseline trace, and signal list. Session Report Generator (SRG) ^TM Our integrated report generator, and project management structure, provide unprecedented sophiscaon in a TSCM application. Multiple Receiver Operation (MRO)^TM Single Receiver Operation (SRO), Dual Receiver Operation (DRO), and Multiple Receiver Operatoon (MRO), are supported with "on‐the‐fly" dynamic (spectrum and demodulation) "hand‐off" between any number and type, of supported receivers and spectrum analyzers. Licensing Options Standard End‐User License Agreement (EULA) includes one (1) full version of the Kestrel TSCM Professional Software, and two Activation Security Keys (ASK), for use with any two (2) supported receivers or analyzers, across two independent host computer installations.

Key features:

Graphical User Interface (GUI)
Ergonometric user interface design promotes operator situational awareness by grouping and dynamically linking essential control elements and use of intelligent automation.
RF Spectrum Display (RSD)
Multiple spectrum tabbed window displays permit any number of frequency Ranges of Interest (ROI) to be searched in parallel.
Waterfall Display (WFD)
Waterfall Display (WFD) and trace recording capability enables the time history of signal events to be instantly reviewed.
Live View Analysis (LVA) ^TMRealtime analysis of continuous and periodic signal events is fully supported without the need to interrupt the data collection process.
Artificial Intelligence
Our Threat Detection Algorithm (TDA) and Signal Combining Technology (SCT) accurately detects and displays wide bandwidth signals.
Kestrel Super Trace (KST)
During remote spectrum surveillance and monitoring over a period of days, weeks, or months, waterfall and trace data can become a storage challenge, and may require extensive post event analysis and review. Our unique data write management feature, in combination with the ability to compress the trace data is a powerful innovation that significantly improves the technical operators analysis and review capability. Waterfall compression method enhances the user‐interface rendering, bringing clarity to the waterfall display. This unique functionality permits the technical operator to easily observe periodic peak energy patterns across the Range of Interest (ROI) over time.

Demodulation and Visualization
The operator can quickly demodulate and record samples of AM, FM and SSB audio. Realtime displays include RF power spectrum, AF power spectrum, audio oscilloscope, IQ and RSSI.
Threat Detection Algorithm (TDA)
Detecon modes include, Minimum Detecon Amplitude (MDA), Harmonic Signature Threshold (HST), and Chirp Threat Mode (CTM).
Differenal Signal Analysis (DSA)
TM Our graphical DSA model permits the import of floor plans, vercal riser, geographical maps and photographs of the target area for direct comparave analysis of all collected data.
Spectrum Baseline Logging (SBL) ^TM
The technical operator can quickly capture a detailed baseline trace, and signal list.
Session Report Generator (SRG) ^TM
Our integrated report generator, and project management structure, provide unprecedented sophiscaon in a TSCM application.
Multiple Receiver Operation (MRO)^TM
Single Receiver Operation (SRO), Dual Receiver Operation (DRO), and Multiple Receiver Operatoon (MRO), are supported with "on‐the‐fly" dynamic (spectrum and demodulation) "hand‐off" between any number and type, of supported receivers and spectrum analyzers.
Licensing Options
Standard End‐User License Agreement (EULA) includes one (1) full version of the Kestrel TSCM Professional Software, and two Activation Security Keys (ASK), for use with any two (2) supported receivers or analyzers, across two independent host computer installations.

Supported receivers:
	SIGNAL HOUND SA‐44B / SA‐124B 1 Hz ‐ 4.4 GHz 100 kHz ‐ 12.4 GHz		SIGNAL HOUND BB60A / BB60C 9 kHz ‐ 6.0 GHz 20 / 27 MHz IF BW 24 GHz / Sec
	ANRITSU "C" SERIES Spectrum Master 9 GHz / 13 GHz / 20 GHz / 32 GHz / 43 GHz		ThinkRF 100 kHz ‐ 8 GHz 100 kHz ‐ 18 GHz 100 kHz ‐ 27 GHz 10 / 100 MHz IF BW
	ROHDE & SCHWARZ Portable Receiver PR100 3.5 GHz / 7.5 GHz		ROHDE & SCHWARZ Portable Receiver EM100 3.5 GHz / 7.5 GHz
	RF Eye NODE 10 MHz ‐ 6 GHz 6 GHz ‐ 18 GHz (BDC) 6 GHz ‐ 50 GHz (BDC)		TEKTRONIX 9 kHz ‐ 6.2 GHz 40 MHz IF BW
	MERLIN MK3^TM 50 kHz to 30 GHz 40 MHz IF Bandwidth
